Working pressure: 1～50KPa。

Electrical load: DC/AC 5V/12V/24/36V Max.1A; 50/60Hz AC 125V/250V Max.3A

Made with internationally advanced membrane boxes, it has excellent qualities such as compact size, easy installation, precise pressure control, and stable performance.

The automatic measurement and control system measures the pressure inside the system to prevent it from being too high or too low and outputting switch signals.

Applicable fluid pressure media: compressed air, industrial gases, water, hydraulic oil, gas, fuel, etc.

Widely used in engine lubrication systems, engine air filtration systems, vacuum systems, ventilation systems, fireplaces, combustion equipment, micro pressure inflation pumps, etc.
