Optional working pressure: 0.1-0.3 bar, 0.2-0.5 bar, 0.3-0.8 bar, 0.8-1.5 bar, 1.5-2.5 bar, 2.5-4bar, 4-6 bar, 6-8 bar, 5-10 bar, 10-15 bar, 15-20 bar, 20-30 bar,

can be customized according to user needs.

Electrical load：5V/12V/24/36 VDC & 5V/12V/24/36 VAC, Max.1A;
                          50/60Hz 110/125/250VAC, Max.3A

The product is made of internationally advanced stainless steel flat membrane pressure sensor (stainless steel flat membrane box, stainless steel flat membrane),

with small size, convenient installation, accurate pressure control, stable performance and other excellent qualities.

It can automatically measure and control the pressure in the system, prevent the pressure in the system from being too high or too low, output switch signals,

and ensure that the equipment works within a safe pressure range.

Suitable for different fluid pressure media: viscous fluids, mortar, coatings, paint, particles, etc.

Widely used in various spray painting equipment, chemical, construction, pharmaceutical, food and other mechanical equipment.
