Product Name: Explosion proof Pressure Switch

Working pressure：-14.5～3600PSI  Optional

Model：PC 250VAC 6A、PC 48VDC 3A

Explosion proof Mark: Ex db IIC T6 Gb,Ex tb IIIC T80℃ Db

Shell protection level: IP67

CCC certificate number: 2022312304001403

Made with internationally advanced stainless steel pressure sensors, the overall stainless steel structure has good waterproof, dust-proof, and explosion-proof performance.

The pressure inside the automatic measurement and control system prevents the pressure inside the system from being too high or too low. It outputs switch signals and plays a role in overpressure and low-pressure alarms.

Ensure that equipment, systems, and personnel work within a safe pressure range.

Suitable for different fluid pressure media: viscous, corrosive fluids such as paint, coatings, butter, etc.

Applied in flammable and explosive hazardous areas, matched with explosion-proof electrical equipment such as pharmaceutical equipment,

petrochemical machinery, spraying machines, printing machines, etc.
