Adjustable pressure range: -100~-10, -50~-5, 5~-1, 1~15, 15~100KPa

Electrical load: DC/AC 5V/12V/24/36V Max.1A; 50/60Hz AC 125V/250V Max.3A

Made with internationally advanced diaphragm (EPDM/Silicon/NBR/stainless steel, optional), it has excellent qualities such as compact size, easy installation, precise pressure control, and stable performance. It automatically measures the pressure inside the system to prevent it from being too high or too low, and outputs switch signals.

Applicable fluid pressure media: compressed air, industrial gases, water, etc.

Widely used in engine lubrication systems, engine air filtration systems, welding equipment, ventilation systems, fireplaces, air purification equipment, etc.
